Stage Right APS 12 400W 12-inch 2-way Active PA System with 3-Channel Mixer
Product # 604212
On Sale 33.53% OFF
Volume Pricing (Log In to see Member Pricing)
(Log In to see Member Pricing)
Qty: 1 $112.99
Qty: 2-9 $112.99
Qty: 10-19 $112.99
Qty: 20-49 $112.99
Qty: 50+ $112.99
|Speaker Type||2-way, bi-amp powered speaker|
|Frequency Response||50Hz ~ 20kHz|
|Low Frequency Driver||12" cone with 2.5" voice coil and 50 oz. magnet|
|High Frequency Driver||1.35" titanium compression driver on 1" throat horn|
|Output Power (RMS)||
Low Frequency: 350 watts
High Frequency: 50 watts
|Output Power (Max)||
Low Frequency: 700 watts
High Frequency: 100 watts
|High Frequency Protection||PTC|
|Sensitivity (1 watt/1 meter, max output)||102dB|
|Maximum Output (SPL)||112dB|
1x 1/4" TS/TRS
1x Combination XLR / 1/4" TS/TRS
|Input Power||115 VAC, 50/60 Hz|
|Power Consumption||16 watts|
|Mounting Points||2x M8x15mm eyebolts on top|
|Pole Socket||ø35mm socket on bottom|
25.0" x 16.9" x 14.2"
(635 x 430 x 360 mm)
|Weight||35.3 lbs. (16 kg)|
- User's Manual (Apr 20, 2016)
Questions and Answers
Browse 16 questions Browse 16 questions and 25 answers
What class of amplifier powers these speakers? Class A, AB, D, Etc?
BEST ANSWER: The APS series speakers are powered by Class D amps.
How is your max SPL calculated? You list a sensitivity of 102 dB @ 1m which is really good. One would expect that a 400W speaker of that sensitivity would produce a much higher SPL at reasonable distances.
BEST ANSWER: Thank you for your interest in the portable PA. Max SPL is 126db. We will work on correcting the product page specs. Thank you.
Is this a stand alone system? What would I need to make this a PA system?
BEST ANSWER: This could be considered a stand alone system if you only need 2 microphones as it has a small built in mixer, if you need more than 2 microphones you would need a separate mixer - but not a powered mixer as the unit has its own amplifier built in. To use as a PA system you would only need microphones and mic cables to connect and possibly a stand for the unit to get it off of the floor.
? Please explain the LOGO, Mix, Loop functions for the Stage Right APS 400W 12-inch 2-way Active Speakers -
Product # 604212
Product # 604212
BEST ANSWER: The logo button is suppose to turn the front logo back light on/off. MIX (button pushed in) allows sound that you hear from the speaker to pass as line level out the balanced XLR to daisy-chain the to another powered speaker. LOOP (button out) routes just inputs 2 & 3 to the XLR. This is usefull for professional musicians to mix their own instruments in to their own amp then send that signal to the house mix.
How are these compared to the 150 watt bi amplifies model for movie playback? Which would be better/louder?
BEST ANSWER: The 400w is plenty loud but you NEED a subwoofer as they do not go very low. With a sub they sound great!
The manual states that this speaker only consumes 16W, is this correct?
BEST ANSWER: Thank you for your interest in this speaker. The APS only consumes 16W at idle. Max consumption is 425W at full power. Thank you for bringing up this issue. We will revise specs and manual.
BEST ANSWER: Thanks for your interest in our Active PA Speaker. The manual states the Treble is ±12db @ 10kHz and the Bass is ±12db @ 100Hz.
3.2 / 5.0
Solid Speaker at a bargain Price
I bought one of these as a back up speaker to the pair of Active powered speakers that I use for my DJ business, the first weekend, I had to put it into service immediately for a wedding ceremony and had my other pair set up at a different part of the venue. The speaker was basically plug and play, had more than enough clear volume for the music and the for the ceremony and all speaking, it was clear and loud enough and did not get too hot. It was summer and heat is always a concern doing any outdoor gigs. Fast forward another week, and I used it as a 3rd speaker as an extension for an outdoor gig where I was blasting music for 4 hours straight. The speaker bailed me out not just the first weekend but again the 2nd week. Easy to use, the sound was actually impressive. I was completely impressed at how well it held up, the volume was great (I purchased a 12") and didnt expect crazy amounts of bass, like far too many people expect when they buy these 10 or 12 inch speakers.. I set it to what I thought was a good eq setting and blasted music, it didnt peak out too easy, didnt distort, I found the setting that I could push it without it clipping and the speaker did wonderful for the whole event. It is lightweight and easy to lift onto a speaker stand. it sounded great, but I wasnt expecting it to sound like a $1200 speaker, but I will say that it our performs many budget active speakers on the market that begin with the letter B and have a yellow triangle in their logo. They are a good solid choice if you are on a budget, or if you need some speakers for speaking engagements and such, pair them up with subs and you will have a great system that sounds like you spent many hundreds of dollars more. my only complaints would be in the design, the knobs are not protected so they can be easily damaged in transport, if they were recessed it would be much better and I wish Monoprice sold a protective bag case for them to transport./ Sound quality for speech and music was way beyond expectations and easily manageable with a little EQ tweeking. There are definitely much worse sounding speakers on the market that cost a whole lot more. I ran these for the entire summer and into the fall untill Halloween and not once did it fail on me and it bailed me out of a few jams. well worth the monty and honestly sounds like they cost more. If you want a good solid speaker that wont break your wallet, these are an excellent choice. I plan on purchasing another 12 inch and a pair of 15's to use. :ike I said, they sound like a much more expensive mid level powered speaker. fix the issues with the control knobs on the rear, get them protected more and you have a solid winner here. thanks Monoprice, you continue to amaze me with the value and quality f the products I buy thru you. I have bought speakers, cables, lighting, cell phone accessories, and many other products, very rarely have I had a problem with anything, and if there was an issue the customer service was outstanding. How about getting some carrying bags protective cases for these speakers and you will have a home run!!
November 16, 2017
9 months ago
9 months ago
Two flaws in my unit
The unit I just received (12" version) has improperly installed treble and bass controls (rotated 90 degrees counterclockwise), and the logo light does not turn on. I wouldn't want the logo lit up anyway, but the rotated EQ controls are annoying. I purchased two of the 10" units several months ago and they are perfect.
February 12, 2018
1 month ago
1 month ago
