Blackbird 4K HDBaseT Slim Extender Kit for Residential, 4K at 100m, ARC, HDCP 2.2, Ethernet, 2 Way PoH
Monoprice's Blackbird 4K HDBaseT Slim Extender Kit transmits high-definition signals at resolutions up to 4K@60Hz. The HDBaseT™ ports support transmission of 4K video to distances up to 100m and 1080p video to distances up to 150m. It supports bidirectional Infrared and RS232 control. The transmission mode is selectable via front panel switch.
This kit has 4 Ethernet ports to work as ethernet switch. The unit is controllable via front panel switch, bidirectional IR, and RS232. In addition, this Blackbird 4K HDBaseT Extender supports the Audio Return Channel feature, which makes it easy to integrate with a home entertainment audio system.
- Supports HDCP2.2 and is backwards compatible with all previous HDMI standards
- Supports resolutions 4K@60Hz, including 1080p 3D
- Transmits 4K signal up to 100m and 1080p signal up to 150m over a single Cat5e/Cat6 cable
- Intuitive front panel control switch
- Supports the Consumer Electronic Control (CEC) and Audio Return Channel (ARC) features
- Supports bidirectional PoH
- Bidirectional IR and RS232 control
- Includes Ethernet switch functionality
- IR accessories not included
|Transmitter Inputs||1x HDMI®, 1x IR (3.5mm), 1x Ethernet (RJ45), 1x RS232|
|Transmitter Outputs||1x HDBT (RJ45), 1x Digital Audio (S/PDIF), 1x Analog Audio (RCA), 1x IR (3.5mm)|
|Receiver Inputs||1x HDBT (RJ45), 1x IR (3.5mm), 3x Ethernet (RJ45), 1x Digital Audio (S/PDIF), 1x RS232|
|Receiver Outputs||1x HDMI, 1x IR (3.5mm)|
|4K Transmission Distance||up to 328 feet (100 meters)|
|1080p Transmission Distance||492 feet (150 meters)|
|Operating Temperature||+32 ~ +122°F (0 ~ +50°C)|
|Operating Humidity||10 ~ 90% RH, noncondensing|
|Input Power||12 VDC, 2A|
|AC Adapter Input Power||100 ~ 240 VAC, 50/60 Hz|
|Transmitter Power Consumption||6 watts|
|Receiver Power Consumption||8 watts|
|Transmitter Dimensions||7.7" x 0.7" x 3.9" (196 x 19 x 100 mm)|
|Receiver Dimensions||7.7" x 0.7" x 3.9" (196 x 19 x 100 mm)|
|Transmitter Weight||10.4 oz. (294g)|
|Receiver Weight||11.8 oz. (335g)|
Blackbird™ is a trademark of Monoprice Inc.
HDBaseT™ and the HDBaseT Alliance logo are trademarks of the HDBaseT Alliance.
HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
