    5-Port 10/100/1000 Mbps Unmanaged Gigabit Ethernet Switch
    Product # 15762
    $11.99 $14.99 On Sale 20.01% OFF
    In Stock This item should ship today (11/23/2017) if ordered within 5 hours 17 minutes

    Volume Pricing (Log In to see Member Pricing)

    Volume Pricing

    Qty: 1 $11.99 $14.99
    Qty: 2-9 $11.99 $14.49
    Qty: 10-19 $11.99 $13.99
    Qty: 20-49 $11.99 $13.49
    Qty: 50+ $11.99 $12.99

    To see and take advantage of our member pricing sign up for a business account or contact our sales team.

    Learn more about Monoprice Business

    5-Port 10/100/1000 Mbps Unmanaged Gigabit Ethernet Switch



    This Unmanaged Gigabit Ethernet Switch adds five bidirectional Ethernet ports for connecting a broadband source and up to four downstream computers or additional network nodes. The switch supports 4K MAC address table entries with self-learning and auto-aging. It supports the IEEE 802.3, 802.3u, and 802.3ab standards, as well as 802.3x flow control for networking speeds up to 1000 Mbps.



    Gigabit Speed
    Intelligent Recognition
    Simple Installation

    Gigabit Speed

    Intelligent Recognition

    Simple Installation

    Gigabit Speed: Provides eight adaptive Gigabit Ethernet ports with wire-speed forwarding, for network speeds up to 1000Mbps.

    Intelligent Recognition: Each bidirectional port can serve as an upstream or downstream port for connecting to a broadband source, computer, or additional network node.

    Simple Installation: Installation is as simple as plugging it in. There is no software setup, driver installation, or firmware configuration required - just plug it in and start using it right out of the box.



    5-Port Gigabit Switch


    1 Year Warranty

    Warranty

    Monoprice not only stands behind every product we sell with a 1 year replacement warranty, we offer a 30-day money back guarantee as well! If the product you purchase does not satisfy your needs, send it back for a full refund.



    Quality at a Fair Price

    Quality at a Fair Price

    Monoprice's rugged design and rigid quality control standards deliver high quality products at fair prices.



    Service & Support

    Service & Support

    You're never on your own with Monoprice products! We have a full team of friendly and knowledgeable technicians available to answer your questions, both before and after the sale. Contact our technical support team for questions about our products, troubleshooting, or even suggestions for products to fit your particular needs. Not to be outdone, our friendly and helpful customer service team is here to make your ordering, delivery, and any possible returns a quick and painless operation, from start to finish!





    Model 15762 15763
    Backplane Bandwidth 10 Gbps 16 Gbps
    Supported Standards IEEE 802.3 10Base-T Ethernet
    IEEE 802.3u 100Base-TX Fast Ethernet
    IEEE 802.3ab Gigabit Ethernet
    IEEE 802.3x Flow control support for full-duplex
    IEEE 802.3 10Base-T Ethernet
    IEEE 802.3u 100Base-TX Fast Ethernet
    IEEE 802.3ab Gigabit Ethernet
    IEEE 802.3x Flow control support for full-duplex
    Protocol CSMA / CD CSMA / CD
    Topology Star Star
    Network Cables 10Base-T: Cat.3 UTP or better
    100Base-TX: Cat.5 UTP / STP
    1000Base-T: Cat.5, Cat.5e, or Cat.6 UTP / STP
    10Base-T: Cat.3 UTP or better
    100Base-TX: Cat.5 UTP / STP
    1000Base-T: Cat.5, Cat.5e, or Cat.6 UTP / STP
    Speed 10 / 100 / 1000 Mbps 10 / 100 / 1000 Mbps
    Transmission Method Store-and-forward Store-and-forward
    MAC Address Table 4K entries 4K entries
    MAC Address Learning Self-learning, auto-aging Self-learning, auto-aging
    Packet Filtering / Forwarding Rate 14880pps (10Mbps) per port
    148800pps (100Mbps) per port
    1488000pps (1000Mbps) per port
    14880pps (10Mbps) per port
    148800pps (100Mbps) per port
    1488000pps (1000Mbps) per port
    Auto MDI / MDIXa Supported Supported
    NWAY Auto-Negotiation Supported Supported
    Power Source External universal power supply External universal power supply
    Input Voltage 9 VDC, 600mA, tip positive 9 VDC, 600mA, tip positive
    AC Adapter Input Voltage 100 ~ 240 VAC, 50 / 60 Hz, 0.3A 100 ~ 240 VAC, 50 / 60 Hz, 0.3A
    Operating Temperature +32 ~ +104°F (0 ~ +40°C) +32 ~ +104°F (0 ~ +40°C)
    Storage Temperature -40 ~ +158°F (-40 ~ +70°C) -40 ~ +158°F (-40 ~ +70°C)
    Operating Humidity 10 ~ 90% RH, non-condensing 10 ~ 90% RH, non-condensing
    Storage Humidity 5 ~ 90% RH, non-condensing 5 ~ 90% RH, non-condensing



    Start typing your question and we'll check if it was already asked and answered. Learn More
    Browse 7 questions Browse 7 questions and 11 answers
    What does the actual switching fabric support? (1Gb up + 1 Gb down per port would be 2Gb apiece, multiply by 5 is 10Gb, but not all switches are made to spec., hence the question..)
    A shopper on Dec 8, 2016
    BEST ANSWER: I think the specs say it has a Backplane Bandwidth of 10 Gbps or 2x5x1Gbps so that should cover it.
    Does this switch support Auto-MDIX or require crossover cables to connect to another switch?
    New User U on Dec 7, 2016
    BEST ANSWER: The specs say it does.
    Does this include the 9VDC power supply?
    Mark B on Apr 25, 2017
    BEST ANSWER: Thank you for your question. Yes, this product will include the 9VDC power supply.

    Should you require additional assistance, please reach out to our technical support team with a detailed question via any of the methods available here:

    https://www.monoprice.com/help?pn=contact

    Our knowledgeable Technical Support staff would be more than happy to assist. Thank you
    Do the LEDs indicate the connection speed (100Mbps vs Gigabit)?
    A shopper on Jan 18, 2017
    BEST ANSWER: The lights do not indicate speed. They just start to flash when data is being transferred.
    Does the switch support VLAN tagging?
    A shopper on Jan 4, 2017
    BEST ANSWER: Typically you'd need to be able to manage the switch to do that. This is an unmanaged switch.
    Do these switches support 802.1x?
    A shopper on Jan 29, 2017
    BEST ANSWER: Thank you for your question. These switches will support the standards listed below.

    IEEE 802.3 10Base-T Ethernet
    IEEE 802.3u 100Base-TX Fast Ethernet
    IEEE 802.3ab Gigabit Ethernet
    IEEE 802.3x Flow control support for full-duplex
    4.9 / 5.0
    52 Reviews
    5 Stars
    4 Stars
    3 Stars
    2 Stars
    1 Stars
    50
    1
    1
    0
    0
    Installed like a breeze
    This high rating is given mostly for Monoprice excellent customer service. My initial order got lost in transit and it was quickly replaced. The switch installed without any problems and is performing flawlessly. Thank you Monoprice

    PROS: very compact, performs as expected and this model has bottom mounting slots.

    CONS: none
    September 16, 2016
    works great
    Plugged it in and hooke up 3 computers, Linux, Mac and Windows. All work fine.
    Why pay mote ??
    December 9, 2016
    Purchased
    1 year ago
    Perfect Switch
    Recently upgraded the internet speed at the office. Our VOIP phones could only handle 100 Mbps. Adding these 5 port switches to each workstation thus by-passing the phones pass-thru connection solved the issue. Setup was a simple a plugging in the power and plugging in the Cat 5e cables. This inexpensive fix beats replacing VOIP phone at $350 each.

    PROS: Quick easy setup
    September 28, 2016
    Nothing fancy; just works.
    I have this outside in a cabinet to extend my network to the back yard. . I plugged it in and it has worked flawlessly for about 2 months.
    December 18, 2016
    Purchased
    1 year ago
    Works great
    Plugged it in, works great right out of the box, no issues so far!
    March 5, 2017
    Purchased
    9 months ago
    GREAT Switch!!!
    I keep one of these with me for any occasion when I might need a switch and they never disappoint.
    March 20, 2017
    Purchased
    8 months ago
    Works Great
    Just plug it up and watch it go. Nothing to set up or install. Great product.
    December 7, 2016
    Purchased
    1 year ago
    Works well with Google Fiber 1G Network.
    Wanted a simple switch to run a CAT6 cable to the upstairs office. Worked out great.
    February 28, 2017
    Purchased
    9 months ago
    works great
    I have 2 of these working for over a year. Super happy with them and their speed. I plan to buy one more.
    July 9, 2017
    Purchased
    1 year ago
    Great little switch at a great price!!!
    Hooked up av components now i dont have to go behind unit every time.
    February 2, 2017
    Purchased
    10 months ago
