    Blackbird 4K 4x4 HDMI Matrix with 4x Coax Out
    Product # 15749
    $297.49 $349.99 On Sale 15.00% OFF
    In Stock This item should ship tomorrow (11/20/2017) if ordered within 31 minutes

    Volume Pricing (Log In to see Member Pricing)

    Volume Pricing

    Qty: 1 $297.49 $349.99
    Qty: 2-9 $297.49 $339.99
    Qty: 10-19 $297.49 $329.99
    Qty: 20-49 $297.49 $319.99
    Qty: 50+ $297.49 $299.99

    To see and take advantage of our member pricing sign up for a business account or contact our sales team.

    Learn more about Monoprice Business

    Blackbird 4K 4x4 HDMI Matrix with 4x Coax Out

    4K 4x4 HDMI Matrix


    The Blackbird™ 4K 4x4 HDMI® Matrix allows you to connect up to four HDMI sources and independently distribute any source to any of four HDMI displays. It supports video resolutions up to 1080p@60Hz and 4K@30Hz, 3D video, up to 12-bits/channel Deep Color, and high-definition multichannel audio, including Dolby TrueHD™ and DTS-HD Master Audio™. Each video output has a corresponding S/PDIF digital coaxial and a 3.5mm TRS analog audio output for connection to an external amplifier, AV receiver, or powered speakers. The matrix comes with a PC application, which allows for PC control via an RS-232 or Ethernet connection.





    4x4 Matrix
    4K Everyday
    Audio Outputs
    4x4 Matrix
    4K Everyday
    Audio Outputs


    4x4 Matrix: Independently view any of the four sources on any of the four displays.

    4K Everyday: Enjoy video at resolutions up to 4K@30Hz with support for the latest HDMI and HDCP 2.2 specifications.1

    Audio Outputs: In addition to the audio carried over the HDMI cable, the matrix features four S/PDIF digital coaxial and four 3.5mm TRS analog audio outputs.





    4K 4x4 HDMI Matrix


    Works with

    Blu-ray Disc™ and DVD players, satellite and cable receivers, and game consoles, as well as HDMI®-equipped televisions and video projectors.





    Features


    • Independently select any source for viewing on any display
    • Supports HDMI® video resolutions up to 1080p@60Hz and 4K@30Hz
    • Supports Deep Color up to 12-bits/channel
    • Supports high-definition multichannel audio, including 7.1-channel LPCM, Dolby TrueHD™, and DTS-HD Master Audio™
    • Independent EDID control for each source
    • Each video output has a corresponding S/PDIF digital coaxial and 3.5mm TRS analog audio output for use with external amplifiers, AV receivers, or powered speakers
    • Supports HDCP 2.2 and the Audio Return Channel (ARC)
    • Can be controlled using the front panel buttons, the included remote control, or a PC using an RS-232 serial or Ethernet connection
    • Includes software application for PC control via RS-232 or Ethernet





    1 Year Warranty

    Warranty

    Monoprice not only stands behind every product we sell with a 1 year replacement warranty, we offer a 30-day money back guarantee as well! If the product you purchase does not satisfy your needs, send it back for a full refund.



    Quality at a Fair Price

    Quality at a Fair Price

    Monoprice's rugged design and rigid quality control standards deliver high quality products at fair prices.



    Service & Support

    Service & Support

    You're never on your own with Monoprice products! We have a full team of friendly and knowledgeable technicians available to answer your questions, both before and after the sale. Contact our technical support team for questions about our products, troubleshooting, or even suggestions for products to fit your particular needs. Not to be outdone, our friendly and helpful customer service team is here to make your ordering, delivery, and any possible returns a quick and painless operation, from start to finish!






    Model 15749
    Inputs 4x HDMI® video, 1x RS-232 serial, 1x RJ-45 Ethernet
    Outputs 4x HDMI video, 4x RCA digital audio, 4x 3.5mm TRS analog audio
    Maximum Video Resolution 1080p@60Hz, 4K@30Hz
    Maximum Video Bandwidth 300Gbps/channel (900Gbps total)
    Input Power 12 VDC, 2.5A AC power adapter
    AC Adapter Input Power 100 ~ 240 VAC, 50/60 Hz

    Maximum Power Consumption 9 watts
    Standby Power Consumption 0.5 watts
    Operating Temperature +32 ~ +104°F (0 ~ +40°C)
    Storage Temperature -4 ~ +140°F (-20 ~ +60°C)
    Operating Humidity 20~90 % RH (non-condensing)
    Dimensions 17.3" x 4.3" x 1.8" (440 x 110 x 45 mm)
    Weight 2.5 lbs. (1.15 kg)



    Support Files:



    Blackbird™ is a trademark of Monoprice Inc.

    HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

    Blu-ray™ and Blu-ray Disc™ are trademarks of the Blu-ray Disc Association.

    Dolby® and the double-D symbol are registered trademarks of Dolby Laboratories. Dolby TrueHD™ is a trademark of Dolby Laboratories.

    DTS® is a registered trademark and the DTS logos, Symbol, DTS-HD&tradde;, and DTS-HD Master Audio™ are trademarks of DTS, Inc.



    Start typing your question and we'll check if it was already asked and answered. Learn More
    Browse 9 questions Browse 9 questions and 9 answers
    Are there or could there be any issues when connecting to a matrix?
    Marcos H on Feb 13, 2017
    Blackbird 4K 4x4 HDMI Matrix with 4x Coax Out
    Blackbird 4K 4x4 HDMI Matrix with 4x Coax Out
    HDMI Extender Using Cat5e or CAT6 Cable, Extend Up to 98ft
    HDMI Extender Using Cat5e or CAT6 Cable, Extend Up to 98ft
    BEST ANSWER: Thank you for your question. We would not recommend connecting a standalone HDMI extender to a Matrix, Switch, or splitter. Reason being is it will add resistance to the signal and has a high probability of not functioning properly or at all. We would recommend using a Matrix that will have a built in extender, such as PID 8151.

    Should you require additional assistance, please reach out to our technical support team with a detailed question via any of the methods available here:

    https://www.monoprice.com/help?pn=contact

    Our knowledgeable Technical Support staff would be more than happy to assist. Thank you
    Do they work with 4K Matrix Switches or Splitter?
    Ravi M on Jan 10, 2017
    Blackbird 4K 4x4 HDMI Matrix with 4x Coax Out
    Blackbird 4K 4x4 HDMI Matrix with 4x Coax Out
    Blackbird 4K 1x8 HDMI Splitter with 3D Support
    Blackbird 4K 1x8 HDMI Splitter with 3D Support
    SlimRun AV Cable for HDMI Enabled Devices, 100ft
    SlimRun AV Cable for HDMI Enabled Devices, 100ft
    BEST ANSWER: I do not use any 4K devices. Although my components are rated to handle 4K. My home is wired with 60, 50, 40, 30, and 12ft Active HDMI cables that I purchased from Monoprice. I have never had any issues with these cables. All of my 30 - 60ft cables are higher gauge. Optical cables were not an option when I set up my system.
    The Blackbird 1x8 splitter that I use does handle switching from from 720P to 1080i. Although it sometimes has trouble switching back. When it has trouble, I have to cycle power on the splitter and everything resets. This is the only issue that I have with with these components.
    I have the 4x4 version 3.0 (Product # 5704) and I am controlling it via rs232 with my control4 system. Are the rs232 commands on this unit the same for source routing?
    A shopper on Jan 3, 2017
    BEST ANSWER: Hello, thank you for your question. In order to better assist you, please feel free to contact us at tech@monoprice.com with a detailed question and our knowledgeable Technical Support staff would be more than happy to assist. Thank you
    Where can I find a PDF of the user manual?
    A shopper on Feb 16, 2017
    BEST ANSWER: Thank you for your question. We a PDF copy of the User Manual listed under the "Full Specs" on the units webpage. Here is a link to the manual for quick access: https://downloads.monoprice.com/files/manuals/15749_Manual_160601.pdf
    Are rack ears included?
    Quentin J on Dec 13, 2016
    BEST ANSWER: Hello, thank you for your question. This item does not come with rack ears. I hope this clarifies it for you. Thanks!
    The software for a TCP connection keeps disconnecting and timing out. Anyone else having this issue? I have a very simply network setup. Is there another version of the software? (ver1.10). Also are there any firmware updates for the device?
    Kevin M on Feb 3, 2017
    BEST ANSWER: I'm sorry to hear that, please feel free to contact us at tech@monoprice.com with a detailed summary of the issue you are experiencing and our knowledgeable Technical Support staff would be more than happy to assist. Thank you
    Can you daisy chain these to split one screen over 16 displays? Details: One input into one of these that will be split across the four ouputs; then each output is the input to another one of these matrix devices (for a total of 5 matrix devices) - allowing you to spread an image over 16 displays.
    Timothy A on Nov 29, 2016
    BEST ANSWER: It sounds like you're better suited to buy an HDMI splitter(s) for that kind of scenario, but technically it might work. Keep in mind that the more devices you have a signal go through, the more potential problems you will have so I wouldn't recommend that kind of setup.
    Will this switch send one HDMI source to all four screen as one video wall, as well as the ability to set the four individual screens on four separate sources?
    Eddie R on Nov 27, 2016
    BEST ANSWER: Correct, although to make sure you're on the same page, your "video wall" will have 4 identical pictures, not scaled to act as one bigger single picture split between 4 monitors.
    What's the max distance you run your coax from this device to a TV?
    A shopper on Jun 27, 2017
