HDMI® Extender Using Cat5e or CAT6 Cable - Extend Upto 328ft
Take advantage of the new HDBase-T technology to extend your High Speed (1080p) 3D HDMI® and IR remote control signals over a single Cat5e/Cat6 cable!
This HDMI extender can send 1080p HDMI signals with 3D support and HDCP pass-through up to 100 meters (328 ft) using a single Cat5e/Cat6 cable. It has a built-in IR extender function as well, so you can control your source devices from the remote location.
Except for the Cat5e/Cat6 cable, this kit comes with everything you need to make the connection and start using it right away!
Features:
-
Supports uncompressed HDMI signals up to 1080p
-
Supports 340 MHz/3.4 Gbps per channel (10.2 Gbps all channel) bandwidth
-
Supports 16-bit per channel (48-bit total) color depth
-
Supports 3D pass-through
-
Supports HDCP pass-through
-
Supports uncompressed audio such as LPCM
-
Supports compressed audio such as DTS Digital, Dolby Digital (including DTS-HD Master Audio™ and Dolby TrueHD™)
-
Built-in IR extender function
-
Uses IEEE-568B wiring standard for Cat5e/Cat6 cable
-
Gold-plated HDMI connectors
-
FCC, CE, UL (C & US), and RoHS Compliant
Note: Monoprice strongly recommends the use of minimum 24 AWG HDMI cables when connecting a device, such as this extender, between the source and destination devices to ensure minimal signal loss and maximum High Speed signal reliability.
Support Files:
HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
DTS is a registered trademark and the DTS logos, Symbol, DTS-HD and DTS-HD Master Audio are trademarks of DTS, Inc.
Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.
|
|
Related Categories
|
|
Customers who bought this item also bought
|
|
Specifications |
|
Input Signal |
HDMI®, 1.2 volts p-p (TTL) |
|
Output Video |
HDMI |
|
Transmission Distance |
up to 100m at 1080p/60 Hz using UTP Cat5e/6 |
|
Input Video Amplifier Bandwidth |
3.4 Gbps/340 MHz |
|
Interlaced Resolutions (50 & 60 Hz) |
480i, 576i, 1080i |
|
Progressive Resolutions (50 & 60 Hz) |
480p, 576p, 720p, 1080p |
|
External Power Supply |
2x 5V DC @ 2A (included) |
|
Power Consumption (Max) |
5W |
|
Operating Temperature |
0° C to +70° C |
|
Operating Humidity |
10% to 85% RH (no condensation) |
|
Storage Temperature |
-10° C to + 80° C |
|
Storage Humidity |
5% to 85% RH (no condensation) |
|
Size (W-H-D) |
100 x 65 x 25 mm |
|
Weight (Net) |
170 g |
|
Regulatory Approvals |
FCC, CE, UL, RoHS |
Included in the Box:
-
1x HDMI Sender unit
-
1x HDMI Receiver unit
-
1x IR Receiver unit with 48" cable
-
1x IR Emitter unit with 48" cable
-
2x AC Adapters with 44" cord
-
2x L-shaped mounting brackets
-
4x Mounting bracket screws
-
1x User's manual
HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
DTS is a registered trademark and the DTS logos, Symbol, DTS-HD and DTS-HD Master Audio are trademarks of DTS, Inc.
Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.
|
|
|
|
|
| All Customer Reviews - Click here to review for HDMI® Extender Using Cat5e or CAT6 Cable - Extend Upto 328ft. |
Average User Satisfaction Rate
|
 | | Rating:  (2 out of 10) | Reviewer: Bobby from Spring, TX | 3/7/2016 9:11:28 AM |
| | Not as advertised |  Pros: none
Cons: a total waste of my time and money
I ordered this product to extend a security monitor just over 200 feet from the source. After installing using Cat5e wiring the product did not work. I called Monoproice support who then informed me that longer distances required Cat6 wiring. This info was neither on the website nor in directions included with product.I had to return another day and run Cat6 wire. My monitor worked for about ten minutes then quit.It never worked after that. I resorted to buying a 230' fiber optic HDMI cable which did work,
Was this review helpful to you?   |  |
|
| | Rating:  (10 out of 10) | Reviewer: Joseph Lombardo from Bentonville, AR | 1/13/2016 5:59:13 AM |
| | Quick & Easy | Perfect product to solve my home theater issues. Quickly & efficiently shipped, easy to install.
| Was this review helpful to you? | |
|
| | Rating:  (3 out of 10) | Reviewer: santa from Fife, WA | 10/29/2015 6:43:47 PM |
| | Failed to get HDCP link | Pros: Arrived quickly
Cons: Didn't work out of the box.
This device while it did give me a link and power light, refused to even acknowledge HDCP. Used 2 different computers, setup with a short cable run. And no signal. Simplified my whole setup down to just the HDMI extender - 12ft CAT6 - receiver - projector. And nothing. Put a voltage inserter from C2G in place (thinking maybe there was a drop in signal level), still nothing. Get on with chat, and they tell me that they have noticed some problems running everything using short (under 3 ft) cables. I am using Monoprice's 24AWG commercial grade HDMI cables. And that chat representative didn't have a clue. Now I am out of time and have to come up with an alternative solution in 10 days!! Thank you for not helping Monoprice. Going to give the HDBaseT item a shot, hopefully it works.
 by Monoprice Administrator
Hello Santa,
Thank you for your review and my apologies for the issues you have experienced with PID 8122. A shame this didn't work out for your needs. I will be sure to pass this info along to our product team so they can look into the matter further. Thanks for your support and sorry again for any inconvenience this may have caused. Should you have any questions, feel free to contact us!
Regards,
Mark P.
Tech Support Associate
by santa
As a followup, the HDBaseT DID work in my setup, however I still had to simplify my setup (would not work with a HDMI Splitter beyond the receiver device.) If you are not sure which one you need, spare yourself the hassle do not get this item, get PID 10225. It cost a little bit more, but it works SO MUCH better.
| Was this review helpful to you? | |
|
| | | Rating: (3 out of 10) | Reviewer: Anonymous from Durant, IA | 10/6/2015 1:16:21 PM |
| Pros: worked well for 4 weeks 5th week started losing signal
Cons: reliablity
was having to unplug ethernet cable and reconnect worked for a few days not we cannot get it operate any more follow some of the other tips about unplugging power an re connect nothing seems to work now
by Monoprice Administrator
Hello,
Thank you for your review on PID 8122. I sincerely apologize for the recent signal issues experienced with this extender. Just to verify, were there any recent changes made to the setup prior to when this started to occur? When unplugging and reconnecting everything, did you happen to start with the display and end with the source? Can we try testing out the extender with a different source device (cable box, bluray player, etc.)? What about with short (~6ft) ethernet cables just to further isolate what the issue may be? Should those steps not work, please provide me with a bit more info such as the devices connected, the lengths of the all cables (both HDMI and ethernet), and the order number. Thank you and I hope this helps!
Regards,
Gabby V.
Tech Support Associate
| Was this review helpful to you? | |
|
| | Rating:  (1 out of 10) | Reviewer: Joseph Lo from Yorba Linda, CA | 4/1/2015 10:06:02 AM |
| | Flickering image/audio. Cheap | This product did not work right out of the box. I connected it to a camera and ps3 (using a 3 foot patch cable to test it out) The image and audio flickers every 3-5 seconds. After reading other reviews, I decided not to gamble on another one. Sending this one back to monoprice.
| Was this review helpful to you? | |
|
| |
|
