Extend the distance you can run High Speed HDMI® cables with full 1080p support to up to 35 meters with this HDMI repeater!

The adjustable equalizer allows you to tune the performance of the repeater to your specific situation and cable lengths. It will also help reduce the presence of digital noise (aka "sparkles") in the video for a clean and clear picture.

The repeater is compatible with the HDMI 1.3b standard and supports full HDCP pass-through, so you won't have any handshake or copy-protection problems. It supports 12-bit per channel (36-bit total) deep color and high resolution audio, including DTS® Digital, DTS-HD Master Audio™, and Dolby True-HD™.

In most cases the repeater draws its operating power from the HDMI cable itself. Only when the input signal is too weak and the voltage falls below 4.75 volts will an optional AC adapter power supply (not included) be required for use. The optional power supply can be any standard 5 VDC, 2A, power adapter with a 5.5 mm outer cylinder size and a 2.5 mm pin size.

A pair of "L" shaped brackets with mounting screws are included, so you can fix this repeater to a flat surface. Above each HDMI connector is anchor nut, allowing you to screw in a locking bracket to keep the HDMI connector from coming loose. The HDMI connectors are gold-plated to ensure maximum signal quality.

The repeater is RoHS compliant. It is UL listed, and is FCC and CE certified.

For installation, the repeater should be placed as close as possible to the destination device (TV). There is no set standard for adjusting the EQ switch because each situation and each piece of equipment varies. Start with the default 0 setting then try increasing the amount of EQ one click at a time until a clean and reliable signal is seen on the TV.

Features:

• Supports up to 1080p resolution
• Supports 225 MHz/2.25 Gbps per channel (6.75 Gbps all channel) bandwidth
• Supports 12-bt per channel (36-bit all channel) deep color
• HDCP pass-through
• Iron Shell for better EMI elimination
• Supports uncompressed audio, such as LPCM
• Supports compressed audio, such as DTS® Digital, Dolby® Digital (including DTS-HD Master Audio and Dolby True-HD)
• 8 levels of equalization settable by turning the EQ switch from 0 to 7

Please note that whenever any device, such as this repeater or an AV receiver, is inserted between the source and destination devices, Monoprice strongly recommends the use of minimum 24 AWG cables, even for short runs. For cable runs longer than 15 feet, 22 AWG cables are strongly recommended for best results, especially with 1080p signals.

Support Files:

• User's Manual (Aug 5, 2011)
