DI Mini Pedal
Connect your guitar, bass, or keyboard directly to the mixer using this DI Mini Pedal from Monoprice!
This DI box takes a high-impedance, unbalanced 1/4" signal and converts it into a low-impedance, balanced XLR signal for Direct Input to a mixer. This allows you to send the signal over much longer cable runs with significantly less signal loss than you could otherwise.
This active DI box a signal gain switch, which allows you to optionally boost or cut the signal by 20dB, so you can compensate for extremely high-level (hot) or low-level signals. Additionally, it includes a cabinet simulator switch, which when activated fattens up the sound to simulate the sound of a large 4x12" speaker cabinet.
In addition to converting the signal, the pedal includes a true bypass output, so you can continue to connect to your amplifier. A ground lift button breaks the ground connection between the input and output, which can be useful for eliminating hum or ground loops.
This pedal is powered using a 9V AC power adapter with a negative tip, such our 9V Power Supply for Guitar Pedals (PID 611600).
Support Files:
- User's Manual (Aug 27, 2014)
Full Specs
| Specifications | |
|---|---|
| Input | 1/4" unbalanced mono jack |
| Input Impedance | 1 megohm |
| Bypass Output | 1/4" unbalanced mono jack |
| Bypass Output Impedance | 1 kilohm |
| XLR Output | 3-pin XLR balanced mono jack |
| XLR Output Impedance | 1 kilohm |
| Power Requirement | 9V AC adapter with tip negative |
| Current Draw | 12mA |
| Dimensions | 1.8" x 3.7" x 1.9" (46 x 94 x 50 mm) |
