Cat6 24AWG UTP Ethernet Network Patch Cable, 5ft Orange
Save the time and hassle of building Ethernet cables by using fixed-length UTP Cat6 Ethernet Network Cables from Monoprice!
Features:
-
Unshielded Twisted Pair (UTP) Category 6 Ethernet cable
-
24AWG stranded, pure bare copper conductors
-
550MHz bandwidth
-
Snagless cable boot protects the plug retaining clip
-
50µm gold plated contacts
-
5-foot length (tip to tip)
Monoprice Ethernet cables are made of 100% pure bare copper wire, as opposed to copper clad aluminum (CCA) wire, and are therefore fully compliant with UL Code 444 and National Electrical Code TIA-568-C.2 fire and safety standards, which require pure bare copper wire in communications cables.
|
|
Related Categories
|
|
Customers who bought this item also bought
|
|
|
| Cat6 24AWG UTP Ethernet Network Patch Cable, 5ft Orange | | | Question: What's the difference between Cat 5, Cat 5e and Cat 6? Can I use one in place of another? | Answer: The difference is in the bandwith ratings. Cat 5e has a higher bandwidth than Cat 5. Cat 6 has a higher rating than Cat 5e.
They all use RJ45 connectors and are usually interchangeable depending on the bandwidth requirements of your devices. | | Question: What's the difference between UTP and STP? Are these cables shielded? | Answer: UTP stands for Unshielded Twisted Pairs.
STP stands for Shielded Twisted Pairs.
The ethernet standard uses data packet transmission and error correction. Unlike streaming data transmission, this standard simply buffers and repeats until it has a complete instruction set which compensates data transmission errors.
Since UTP was cheaper in the beginning, it generally became the standard. If you are using the cables for ethernet connections, either should work. If you are using for a stream data system like video tranmission, the shielded should be used. | | Question: Is this cable solid or stranded? | | Answer: Stranded. | | Question: Are these cables Power over Ethernet (POE) and Voice Over IP (VOIP) compliant. | | Answer: Yes, our network cables are made to the highest standards and will support all current and emerging new technologies. | | Question: Are these cables rated for in-wall, risers, plenum? | | Answer: These cables are CM rated for in-wall use. They are not rated for risers or plenum. | | Question: What is Plenum? Do I need it? | Answer: Plenum refers to the plenum crawl spaces found above the ceilings of commercial office building. Unless your installation is in a commercial office space, you do not need plenum. Residential applications usually do not require Plenum.
Plenum cables are designed not to produce toxic gases when they are burned. The logic behind this is that in an office building, if a fire broke out in one part of a building, people in other parts of the building may not be aware of the danger but toxic gases being circulated by the air circulation system could knock these people out. | | Question: What is Plenum? Do I need it? | Answer: Plenum refers to the plenum crawl spaces found above the ceilings of commercial office building. Unless your installation is in a commercial office space, you do not need plenum. Residential applications usually do not require Plenum.
Plenum cables are designed not to produce toxic gases when they are burned. The logic behind this is that in an office building, if a fire broke out in one part of a building, people in other parts of the building may not be aware of the danger but toxic gases being circulated by the air circulation system could knock these people out. | | Question: Can Cat6 and Cat6a cables be mixed/ used together? | | Answer: Yes, it's fine to mix Cat6 and Cat6a, but you will only get Cat6 speeds. | | Question: This cable is listed as being "bare copper", does that mean it has no cable jacket or insulation? | Answer: The "bare copper" refers to the construction of the conductors, as specified in the following reference:
Section 5.3 of TIA-568-C.2 requires compliance with ANSI/ICEA SS-90-661-2006 and ANSI/ICEA S-102-732, which both include the following: "Solid conductors shall consist of commercially pure, annealed, bare copper ..."
http://www.cablinginstall.com/index/display/article-display/4838983421/articles/cabling-installation-maintenance/news/network-cable/cat6/2011/3/CCCA-CDA-warn-against-copper-clad-aluminum-cables.html
The problem is that some manufacturer's cut costs by using Copper Clad Aluminum wire for their conductors. The aluminum has a higher resistance, which causes more heat and can thereby present a fire hazard. "Bare copper" is the term used in the National Electrical Code, Underwriters Laboratories, and the Communications Cable and Connectivity Association (CCCA). Our use of the term is intended to communicate our total compliance with their standards for Ethernet cable construction.
|
|
|
|
| All Customer Reviews - Click here to review for Cat6 24AWG UTP Ethernet Network Patch Cable, 5ft Orange. |
Average User Satisfaction Rate
|
 | | Rating:  (10 out of 10) | Reviewer: srk from , | 12/31/2015 4:38:59 PM |
| | Just what I wanted |  Pros: good quality color selection
Cons: none
Ordered this, and 11 other Cat6 cables, to upgrade existing home network with a gigabit connection. I expected great results and none of the cables disappoint. When needing cables in the future, Monoprice is where I'm going.
I highly recommend these cables from Monoprice: the selection was terrific, shipping fast, and customer service impeccable when an unexpected delay in shipping on a couples cables occurred (I was emailed updates and delayed cables were 1 day behind others).
Was this review helpful to you?   |  |
|
| | | Rating: (10 out of 10) | Reviewer: Yuri Aldanov from Norwalk, CA | 5/11/2015 1:05:37 PM |
| | Cable is OK with gigabit connection | Cable is OK with gigabit connection
| Was this review helpful to you? | |
|
| | | Rating: (10 out of 10) | Reviewer: Anonymous from Matthews, NC | 9/29/2013 10:01:25 AM |
| very pleased with purchase - cables are of high quality. Just what I expected.
| Was this review helpful to you? | |
|
| | | Rating: (10 out of 10) | Reviewer: lynrd63 from Austin, TX | 7/5/2013 8:39:07 AM |
| | Great Cables! | Pros: Work great, great price, available in different colors.
Cons: none
These are good quality cables, available in different colors and lengths. I buy all of my cables from Monoprice, whether it is A/V, HDMI or computer related, and I have never received a bad product. The quality is excellent, and so is the price!
| Was this review helpful to you? | |
|
| | | Rating: (10 out of 10) | Reviewer: Daniel Lupisella from Herndon, VA | 11/19/2012 5:55:56 AM |
| Pros: Everything. Price, availability, shipping, etc.
Cons: None yet.
We received the cables quickly and as promised. No problems in shipping or receiving and we have not had a DOA cable yet.
| Was this review helpful to you? | |
|
| |
|
