8-Port USB PS2 Combo KVM Switch with Cable - Retail
-
Console your Keyboard/Mouse via either way of PS/2 and/or USB arbitrarily.
-
Complex connections with PCs via either way of PS/2 and/or USB arbitrarily.
-
Controls 8 computers from a single console (Keyboard/Mouse) over PS/2 and/or USB connections.
-
Supports Windows, Linux, Mac OS9/OSX, Sun Microsystems.
-
On-Screen-Display (OSD) & Daisy Chain functions. - OSD is intuitive menus driven for quick and efficient navigation. - 3 level cascades: up to 3 levels; control up to 64/512 PCs, from a single console; cascaded units don’t need special configuration
-
Emulates a keyboard on each PC to allow your computers to boot normally without a keyboard error.
-
Supports hot-pluggable. All devices connected to the KVM can be added or removed at any time, without shutting the unit down
-
Supports 3 types of switching:
(1) Hardware Push Button, (2) Hot-Keys on PS/2 and/or USB of keyboard, (3) Menu driven OSD ( On Screen Display)
-
Supports Auto-Scan function to switch video automatically among computers in preset intervals sequentially
-
Supports LED display for PC and/or server status monitoring.
-
Supports VGA resolutions up to 2048 x 1536 maximum
-
Supports Beeper during Switching enabled.
-
Powered with external power adaptor connection.
-
Fully compliant with the USB 1.1/ 2.0 specification.
-
Rack Mountable in 19” system tack ( 1U ) Comes with rack mount bracket (ears) and screws,
-
Equipping with OSD and Cascade Chain functions
Item comes with 8 sets of keyboard, mouse, monitor and USB cables. 6ft long.
Power supply is included. 100-240 VOLT o.3A Max, 50-60Hz, OUTPUT 10 Watts, 5V DC Wall Wart
Support Files:
|
|
Related Categories
|
|
Customers who bought this item also bought
|
|
Model |
KCF-181S |
|
Computers Controlled |
8 |
|
Selection Method |
Push Button and Hot-Key (PS/2 and/or USB Keyboard) |
|
LEDs |
Red for PC Selection Green for PC On-Line ready |
|
PC Connectors |
Video |
1 x HDB-15 male |
|
Console Ports |
Keyboard |
1 x 6 pin mini-DIN female |
|
Mouse |
1 x 6 pin mini-DIN female |
|
Video |
1 x HDB-15 female |
|
Keyboard |
1 x USB A type female |
|
Mouse |
1 x USB A type female |
|
Auto-Scan Interval |
From 5 to 250 Seconds |
|
DDC, DDC2 monitor |
Yes (Max. Resolution: 2048x1536)@85Hz |
|
Hot Swappable |
Yes |
|
Operating systems supported |
Windows 98SE /ME /2000 /XP/2003 Server, Linux |
|
Mac OS9/OSX and Sun Micro System |
|
Device driver |
No Need |
|
Power |
By external power adaptor DC 5V |
|
Dimensions (L X W X H) |
44 x 15.7 x 4.5 cm (17.3 x 6.1 x 1.5 inch ) |
|
Housing material |
Metal |
|
Operating Temperature |
32~ 122 (0~ 50 ) |
|
Humidity |
0%~80%RH |
|
|
|
|
|
| All Customer Reviews - Click here to review for 8-Port USB PS2 Combo KVM Switch with Cable - Retail . |
Average User Satisfaction Rate
|
 | | Rating:  (9 out of 10) | Reviewer: Anonymous from Smithtown, NY | 6/18/2015 8:59:47 AM |
| | Works Right Out Of The Box |  Pros: 1) Comes with rack brackets and AC adapter. (4 port version doesn't)
2) Has no problem working with Dell keyboard, model KB212-B. (4 port version does)
Cons: none
There was just one minor issue when connecting the eight computers to this. A server running Windows Server 2008 Standard keeps giving an error message that the driver for the device was found, but failed to load. I think this is more of a security setting problem with the OS more than anything else. The other 7 computers are working fine off of it.
Was this review helpful to you?   |  |
|
| | Rating:  (8 out of 10) | Reviewer: Anonymous from Houston, TX | 3/17/2015 2:14:03 PM |
| | Cheap Mid-grade KVM | This KVM is cheap and easily rackmounts. The KVM has separate, DEDICATED USB ports, one for keyboard, one for mouse. This is good if you are using separate devices, but we have a IBM rackmount console with a combination keyboard/trackball/trackpoint device that has a single USB cord. This KVM does not work with the combo pointer/keyboard device. I have also had issues with the KVM recognizing some keyboards and mice which have additional nonstandard buttons on them.
| Was this review helpful to you? | |
|
| | Rating:  (10 out of 10) | Reviewer: Nathan from Modesto, CA | 2/24/2015 10:41:33 AM |
| Pros: Works great and is a good value.
Cons: None
Arrived in a timely manor and works great!
| Was this review helpful to you? | |
|
| | Rating:  (1 out of 10) | Reviewer: David The Gom from , | 8/27/2014 5:36:28 PM |
| | No replacement cable? Are you joking? | Pros: Works very well.
Cascading capability makes this switch a beast.
Cons: 6 ft cable
No replacement available.
Bought this to use in my work as an IT. 4 cables missing. I tried to buy additional cable, but they don't have it. Then the rep said that they are the manufacturer of this unit. Ok, so, they are the manufacturer, but they are not selling any replacement cable.
Be aware, if you lose or break any cable, you cannot get replacement (even if you are willing to pay for it!!!!)
 by Monoprice Administrator
Hello,
Thank you for your review and truly sorry to hear about the experience you have had with PID 3407. Do you happen to have the order number for that purchase? I can look into this further to see if there is anything we can do. Also, I will be putting in a suggestion to our product development team to see if we can carry the cables needed for this KVM switch separately. Apologies for any inconvenience this may have caused and thank you for the feedback!
Regards,
Gabby Villa
Tech Support Associate
| Was this review helpful to you? | |
|
| | | Rating: (9 out of 10) | Reviewer: TennisAce from Saanichton, BC | 1/3/2014 8:21:57 AM |
| | Great Value for acombo KVM | Pros: Easy to setup
Comes with all the cables
Works with combination of PS2 and USB
Cons: 6 ft cables may be too short for some applications
This was my second of these units and it replaced another brand which kept dropping connections requiring constant resets. Since installing the Monoprice unit I have not reset once. It just works.
| Was this review helpful to you? | |
|
| |
|
