14FT 24AWG Cat6 500MHz Crossover Bare Copper Ethernet Network Cable - Red
An Ethernet Crossover cable is used to connect two PCs directly together, without using a hub or switch in between. Each cable is made of 24AWG stranded pure copper conductor pairs with 50µm gold plated contacts (short body). Most budget cables skimp with only 10µm. Each cable features color matched, snagless, strain relief boots.
Monoprice Cat5e and Cat6 cables are made of 100% pure bare copper wire, as opposed to copper clad aluminum (CCA) wire, and are therefore fully compliant with UL Code 444 and National Electrical Code TIA-568-C.2 fire and safety standards, which require pure bare copper wire in Cat5e and Cat6 communications cables.
|
|
Related Categories
|
|
Customers who bought this item also bought
|
|
|
| 14FT 24AWG Cat6 500MHz Crossover Bare Copper Ethernet Network Cable - Red | | | Question: What's the difference between Cat 5, Cat 5e and Cat 6? Can I use one in place of another? | Answer: The difference is in the bandwith ratings. Cat 5e has a higher bandwidth than Cat 5. Cat 6 has a higher rating than Cat 5e.
They all use RJ45 connectors and are usually interchangeable depending on the bandwidth requirements of your devices. | | Question: What's the difference between UTP and STP? Are these cables shielded? | Answer: UTP stands for Unshielded Twisted Pairs.
STP stands for Shielded Twisted Pairs.
The ethernet standard uses data packet transmission and error correction. Unlike streaming data transmission, this standard simply buffers and repeats until it has a complete instruction set which compensates data transmission errors.
Since UTP was cheaper in the beginning, it generally became the standard. If you are using the cables for ethernet connections, either should work. If you are using for a stream data system like video tranmission, the shielded should be used. | | Question: Is this cable solid or stranded? | | Answer: Stranded. | | Question: Are these cables Power over Ethernet (POE) and Voice Over IP (VOIP) compliant. | | Answer: Yes, our network cables are made to the highest standards and will support all current and emerging new technologies. | | Question: Are these cables rated for in-wall, risers, plenum? | | Answer: These cables are CM rated for in-wall use. They are not rated for risers or plenum. | | Question: What is Plenum? Do I need it? | Answer: Plenum refers to the plenum crawl spaces found above the ceilings of commercial office building. Unless your installation is in a commercial office space, you do not need plenum. Residential applications usually do not require Plenum.
Plenum cables are designed not to produce toxic gases when they are burned. The logic behind this is that in an office building, if a fire broke out in one part of a building, people in other parts of the building may not be aware of the danger but toxic gases being circulated by the air circulation system could knock these people out. | | Question: What is Plenum? Do I need it? | Answer: Plenum refers to the plenum crawl spaces found above the ceilings of commercial office building. Unless your installation is in a commercial office space, you do not need plenum. Residential applications usually do not require Plenum.
Plenum cables are designed not to produce toxic gases when they are burned. The logic behind this is that in an office building, if a fire broke out in one part of a building, people in other parts of the building may not be aware of the danger but toxic gases being circulated by the air circulation system could knock these people out. | | Question: Can Cat6 and Cat6a cables be mixed/ used together? | | Answer: Yes, it's fine to mix Cat6 and Cat6a, but you will only get Cat6 speeds. | | Question: This cable is listed as being "bare copper", does that mean it has no cable jacket or insulation? | Answer: The "bare copper" refers to the construction of the conductors, as specified in the following reference:
Section 5.3 of TIA-568-C.2 requires compliance with ANSI/ICEA SS-90-661-2006 and ANSI/ICEA S-102-732, which both include the following: "Solid conductors shall consist of commercially pure, annealed, bare copper ..."
http://www.cablinginstall.com/index/display/article-display/4838983421/articles/cabling-installation-maintenance/news/network-cable/cat6/2011/3/CCCA-CDA-warn-against-copper-clad-aluminum-cables.html
The problem is that some manufacturer's cut costs by using Copper Clad Aluminum wire for their conductors. The aluminum has a higher resistance, which causes more heat and can thereby present a fire hazard. "Bare copper" is the term used in the National Electrical Code, Underwriters Laboratories, and the Communications Cable and Connectivity Association (CCCA). Our use of the term is intended to communicate our total compliance with their standards for Ethernet cable construction.
|
|
|
|
| All Customer Reviews - Click here to review for 14FT 24AWG Cat6 500MHz Crossover Bare Copper Ethernet Network Cable - Red . |
Average User Satisfaction Rate
|
|
Monoprice welcomes your feedback. The review you submit will be displayed on the product's review page after it has been verified. It should take about 2-3 business days for this process. Monoprice verifies customer reviews and will publish them after making sure they comply with our review guidelines. You may be contacted by Monoprice regarding your submission.
We will remove reviews that: - Contain profanity or other objectionable content. Should you find any profanity or objectionable content, please contact us at tech@monoprice.com
- Fail to focus on the product. Complaints about shipping or customer service issues will be forwarded to Customer Service to be addressed. Reviews that discuss other products, catalog copy, pricing, or other ancillary issues will be removed.
- Contain advertisements or promotional materials or contain links to external content. Monoprice will also remove reviews submitted by or on behalf of a company with an interest in a competing product.
- Any other content we deem to be inappropriate.
If you believe you may have received a defective unit, remember that Monoprice backs everything we sell with a warranty. Please use our automated return service to request a replacement. Any other issues with your order not directly related to the product itself should be directed to our online customer support chat.
Note: All or part of any product review including the Review Title, "Your Nickname", Rating, Pros/Cons, images and all other parts of the review itself may be used by Monoprice in future marketing campaigns or promotions in any media. Submission of a product review signifies consent that the information you submit may be used at Monoprice's discretion without any further notice or expectation of compensation. You are further representing that any submission is wholly an original creation by you and/or that any portion taken from third party sources have fully cleared for use.
|
|
If you want to write a review, please login first by clicking here.
|
|
|
(100%)
rated by 2 user(s)
(10 out of 10)
It works just fine. For those times when a router or switch goes tits-up and you need to network quickly. From that i can assume it'll work well for connecting consoles.
