Simplify the task of running distributed audio for restaurants, hotels, or anywhere large areas need background music and/or paging address systems. Connect hundreds of speakers covering acres of area without the need for large equipment racks.

A constant voltage speaker system differs from a traditional 8-ohm speaker system in that it uses a step-up transformer at the audio source to raise the voltage and lower the current on the transmission line. At the speaker end, a step-down transformer converts the signal back to a normal speaker level voltage. This reduces power loss during transmission, which allows for the use of longer speaker wire runs using smaller gauge wire.

Additionally, a constant voltage speaker system allows for the use of multiple speakers on each channel, without the need for complicated impedance calculations and configurations. In a constant voltage system, all speakers on a given channel are connected in parallel and the complicated impedance calculations are replaced by simple wattage calculations.

For example, if you want to connect two speakers per channel in a traditional 8- ohm speaker system, you must either connect them in series, which results in an overall 16-ohm impedance, or in parallel, which results in an overall 4-ohm impedance. In the first case, the 16-ohms impedance effectively halves the output power of your amplifier, resulting in lower overall volume levels. In the latter case, the 4-ohms impedance means that your amplifier will have to work harder and must be rated as stable at 4 ohms. Adding a third speaker to the mix would complicate it further, producing either a 24-ohm or 2-ohm overall impedance. Note that very few amplifiers are stable under 2-ohm loads, so that is usually not an option.

On the other hand, with a constant voltage system, you consider first the RMS output wattage of the amplifier. This should be reduced by 20% to compensate for insertion loss. For example, if using a 100-watt amplifier, the total load from speakers should not exceed 80 watts.

Line level inputs can automatically be turned down when speaking into Mic 1. Line level inputs are automatically shut off when emergency system are connected and active, allowing patrons the hear alarms or directions given via Mic 1. Heavy duty construction allows the unit to run all day everyday with reliable audio and consistent performance. Line out allows interfacing with additional audio systems.

Features:

• XLR & 1/4" mic inputs, RCA stereo line inputs, RCA stereo line out
• Emergency trigger all off except for Mic 1 + Mic ducking (auto attenuation of line ins when mic is in use)
• 70/100V allows numerous speakers to be connected without complicated impedance calculations
• Plug and play configuration

Support Files:

• User's Manual (Dec 10, 2015)
