3G SDI 4x1 Switch
Designed for professional SMPTE video applications, this 3G SDI 4x1 Switch allows you to determine which of two connected SDI video sources will be displayed on the SDI monitor. This switch supports bit rates up to 2.970 Gbps and supports SD-SDI, HD-SDI, and 3G-SDI video signals.
Features:
-
Features equalizer circuitry on the inputs and outputs, allowing it to support long cable runs
-
Support for multiple standard and high definition video resolutions:
-
SD 525i and 625i
-
HD 720p @ 24, 25, 30, 50, and 60 Hz
-
HD 1080i @ 50, 60 Hz
-
HD 1080p @ 24, 25, and Hz
-
3G 1080p @ 50, 60 Hz
-
Support for multiple color spaces:
-
RGB or YCbCr 4:4:4 sampled
-
YCbCr 4:2:2 sampled
-
Supports data rates: 270Mbps～2.97Gbps
-
Supports 8-bit, 10-bit, and 12-bit Deep Color
-
Compatible with the HDcctv 1.0, HD-SDI (ST 292), 3G-SDI (ST 424), and SD-SDI (ST 259) standards
|
|
Customers who bought this item also bought
|
|
Specifications |
|
Input Connector |
4x SDI BNC Male |
|
Output Connector |
1x SDI BNC Male |
Supported Cable Length
(using RG59 cable) |
3G (1080p 60Hz) Mode: up to 262 ft (80m)
HD (720p 60Hz) Mode: up to 393 ft (120m)
SD (480i) Mode: up to 656 ft (200m) |
|
Dimensions (LxWxH) |
6.4" x 3.3" x 1.0" (162 x 85 x 25mm) |
|
Weight (Net) |
13.4 oz. (380g) |
|
Operating Temperature |
+32 to +158°F (0 to +70°C) |
|
Operating Humidity |
10% to 85% RH (no condensation) |
|
Storage Temperature |
+14 to +176°F (-10 to +80°C) |
|
Storage Humidity |
5% to 90% RH (no condensation) |
|
AC Adapter Input |
100-240 VAC, 50/60 Hz |
|
AC Adapter Output |
5 VDC, 2A |
|
Power Consumption (Max) |
3W |
|
Regulatory Compliance |
FCC, CE, UL Listed (C+US) |
Included in the Package:
-
1x 3G SDI 4x1 switch
-
1x AC power adapter with 44" cord
-
1x User's manual
|
|
|
|
|
| All Customer Reviews - Click here to review for 3G SDI 4x1 Switch. |
Average User Satisfaction Rate
|
 | | Rating:  (10 out of 10) | Reviewer: Anonymous from Van Nuys, CA | 8/7/2015 6:36:42 PM |
| | Awesome |  Pros: Works
It works great. It inserts a few frames of black during a switch, but that's to be expected from any switcher in this price range. It only has one button to cycle through inputs it would be better to have 4 buttons. But the RS-232 port solves this problem for me.
The serial commands posted by TVGuy are correct, thank you. When sending serial commands, you need to use a carriage return, rather than line feed.
Was this review helpful to you?   |  |
|
| | | Rating: (10 out of 10) | Reviewer: Steven Friedman from Glendale, CA | 12/2/2013 10:51:07 PM |
| Pros: Reliable SDI switcher at a great price
Cons: LED lights are pretty bright, but no big deal. Wish there was an 8x1
A great device for switching between 4 different HDSDI feeds, Does the job, simple and straight foward, you won't find anything better at this price.
| Was this review helpful to you? | |
|
| | Rating:  (8 out of 10) | Reviewer: Mikethesoundguy from Arlington, TX | 10/9/2013 10:33:40 AM |
| Pros: Fast switch
Cons: I would like a model with a button for each input to jump to that input. but for the price great product.
Works well. Great product.
| Was this review helpful to you? | |
|
| | Rating:  (6 out of 10) | Reviewer: TVGuy from Surprise, AZ | 9/4/2013 8:49:58 AM |
| Pros: Easy to Set up, decently built.
Cons: Does not include RS232 Commnads. 5v Power Supply - Every other piece of SDI equipment I have uses a 12v.
Purchased this product to use as a remote switch with RS232 control. Unfortunately the RS232 commands were not included and after contacting Monoprice support, no one could locate them. 2 weeks later Monoprice sent them to me. I've knocked off a few points for releasing a product that wasn't properly documented and having to wait 2 weeks to be able to use it.
For reference, here are the connection information and commands:
9600,N,8,1
The Command codes are “1” , ”2” , ”3” , ”4”
| Was this review helpful to you? | |
|
| |
|
